DS-96256NI-I16 256 Channel SERIES NVR

_______________________________________________________________________________________________________________________________________

Video/Audio Input

Two-way audio input:

1-ch, RCA (2.0 Vp-p, 1kΩ)

IP video input:

256-ch

_______________________________________________________________________________________________________________________________________

Network

Remote connection:

256

Incoming bandwidth:

768Mbps

Outgoing bandwidth:

768Mbps

_______________________________________________________________________________________________________________________________________

Video/Audio Output

HDMI Output:

2-ch, resolution: 4K(4096*2160)/60Hz, 4K(3840*2160)/30Hz, 2K(2560*1440)/60HZ, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Recording Resolution:

12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Audio Output:

1-ch, RCA (2.0Vp-p, 1KΩ)

VGA Output:

1-ch, resolution: 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

_______________________________________________________________________________________________________________________________________

Decoding

Capability:

20-ch@1080P

Live view / Playback:

12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

_______________________________________________________________________________________________________________________________________

Hard Disk

eSATA:

1 eSATA interface

miniSAS (Optional):

2 miniSAS interface

Capacity:

Up to 8TB capacity for each HDD

_______________________________________________________________________________________________________________________________________

Disk array

Array type:

RAID0, RAID1, RAID5, RAID6, RAID10

Number of array:

8

_______________________________________________________________________________________________________________________________________

External Interface

Optic fiber interface:

4 1000 Mbps optional optic fiber interfaces

Network Interface:

4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces

Serial Interface:

RS-232, RS-485, Keyboard

USB Interface:

Front panel: 2 × USB 2.0
Rear panel: 2 × USB 3.0

Alarm In:

16-ch

Alarm Out:

4-ch

_______________________________________________________________________________________________________________________________________

General

Power Supply:

100-240 VAC, 550W

Consumption(without hard disk and POE):

≤ 140W

Working Temperature:

0 oC ~ +50 oC (32oF ~ 122oF)

Working Humidity:

10 % ~ 90 %

Chassis:

3U chassis

Dimensions:

442 × 494 146 mm (17.4 × 19.4 5.7 inch)

Weight(without HDD):

≤16kg (35.3lb)
